WR42 BJ220 To K2.92mm Female End Launch Waveguide To Coax Adapter 17.6GHz~26.7GHz

Brand Name : ELT

Model Number : K/BJ220-KFE7

Certification : ISO 9001:2015, ISO 14001:2015

Place of Origin : China

MOQ : 5 pcs

Price : Negotiable

Payment Terms : T/T, L/C, Credit Card, Paypal

Supply Ability : 10,0000 pcs per month

Delivery Time : Within 5-7 workdays(for stocks)

Packaging Details : Standard Export Carton

Product Name : WR42 K2.92mm Waveguide to Coaxial Adapters

Material : Brass

Frequency Range : 17.6GHz-26.7GHz

Connector : K2.92mm

VSWR : 1.35

Impedance : 50 Ohm

Waveguide Size : WR42,BJ220

Body Style : End Launch

Contact Now

WR42 BJ220 To K2.92mm Female End Launch Waveguide To Coax Adapter 17.6GHz~26.7GHz

The frequency of wave-guide to coax adapters processed by Elite Electronic (ELT) cover 5.4GHz-110GHz. With high reliability, small size and excellent performance, it is widely used in microwave measurement and millimeter wave equipment. The waveguide has standard rectangular and double-ridge waveguides, and non-standard waveguides can be customized according to user requirements. The coaxial end connection interface includes N, TNC, SMA, SMP,SSMP, 3.5, K (2.92), 2.4, 1.85, 1.0 and microstrip. Waveguide to coax adapters are divided into two types: end Launch and right angle launch from interface orientation. Among them, the RA launch type can also be used as a high-power structure.

Specification of K/BJ220-KFE7:

Product Name WR42 Waveguide to K2.92mm Coaxial Adapters
Model No. K/BJ220-KFE7
Coaxial type K2.92mm
Waveguide Size WR42 (BJ220)
Body Style End Launch
Frequency Range 17.6-26.7GHz
SMA Impedance 50 Ohm
VSWR 1.30

Advantages:
-Our waveguide adapters are of high reliability, miniature size and excellent performance etc, which makes them extensively adopted in microwave measurement and millimeter wave devices etc.
Outline Drawing and Pictures of WR42 BJ220 to 2.92mm Female Waveguide to Coax Adapter K/BJ220-KFE7:
WR42 BJ220 To K2.92mm Female End Launch Waveguide To Coax Adapter 17.6GHz~26.7GHz

List of Waveguide to 2.92mm Coaxial Adapters:

Model Number Description Note
K/BJ220-KF6 WR42(BJ220) to 2.92mm female right angle adapters
K/BJ220-KFE7 WR42(BJ220) to 2.92mm female end launch adapters BJ220=WR42
Custom Type Customized sizes are acceptable

WR42 BJ220 To K2.92mm Female End Launch Waveguide To Coax Adapter 17.6GHz~26.7GHz

WR42 BJ220 To K2.92mm Female End Launch Waveguide To Coax Adapter 17.6GHz~26.7GHz

Cross-references of waveguide Standards

Chinese Standards International Standards Frequency Range (GHz)
BJ84 WR112 6.57~9.99
BJ100 WR90 8.20~12.5
BJ120 WR75 9.84~15.0
BJ140 WR62 11.9~18.0
BJ180 WR51 14.5~22.0
BJ220 WR42 17.6~26.7
BJ260 WR34 21.7~33.0
BJ320 WR28 26.3~40.0
BJ400 WR22 32.9~50.1
BJ500 WR18 39.2~59.6
BJ620 WR14 49.8~75.8
BJ740 WR12 60.5~91.9
BJ900 WR10 73.8~112

Waveguide to Coax Adapter-ELT 2024.pdf

NOTE:
We have over 1,000 types of Waveguide to Coaxial Adapters for choice, if the adapter you are using is not found, please contact us with your details. ODM dimension is welcomed.
